NSK – Angular contact ball bearings – 3307 BTNG

3307 BTNG

Dimensions	0,088 × 0,088 × 0,052 mm
HS code	84821090
Inner dimension	35 mm
Outer dimension	80 mm
Width	34,9 mm
Weight	0,72 kg
Seal	None, open bearing
Clearance	Normal radial clearance
Cage	Polyamide cage
Temperature range	-20 to +120 °C
Tolerance class	Tolerance class P0/PN2 / ABEC 1
Arrangement	Bearing pair with a low axial clearance in O- and X-arrangem
Contact angle	40 degree
Outer ring	Without flange/groove
Ball rows	Double row bearing
Material	Standard bearing steel
Brand	NSK
