NTN – Angular contact ball bearings – 5307 S

5307 S

HS code	84821090
Inner dimension	35 mm
Outer dimension	80 mm
Width	34,9 mm
Weight	0,77 kg
Material	Standard bearing steel
Seal	None, open bearing
Clearance	Normal radial clearance
Cage	Sheet steel cage
Temperature range	-20 to +150 °C
Arrangement	Standard version
Tolerance class	Tolerance class P0/PN2 / ABEC 1
Ball rows	Double row bearing
Contact angle	Without indication, usually 30-40 degrees
Outer ring	Without flange/groove
Brand	NTN

Dimensions

Dimensions	0,09 × 0,09 × 0,055 mm
